Product details
| Manufacturer: | SawStop |
| Part Number: | ICS31230-TGI236 |
| MPN: | ICS31230-TGI236 |
The SawStop® Industrial Cabinet Saw is the epitome of industrial-grade performance, recognized as the heaviest, most powerful, and highest-quality 10" cabinet saw available. With a robust 3HP, 1-phase, 230V configuration, this cabinet saw is engineered to tackle the most demanding woodworking projects with precision and ease. Equipped with a 36? Industrial T-Glide Fence Assembly, it offers exceptional durability and versatility, making it perfect for both professional woodworkers and serious hobbyists. Plus, with SawStop’s patented safety system, you can work with confidence, knowing you have industry-leading protection against accidental blade contact.
- 69-1/4"W x 36-1/2"D x 34"H
- Durable craftmanship and thoughtful details combine for consistent, reliable performance in the most demanding industrial environments
- SawStop Safety System stops on contact with skin
- 36" Industrial T-Glide Fence System provides smooth operation, an expansive work surface, precision measurement and sure lockdown without deflection.
- Includes 4 boxes:
- ICS31230
- TGI2-FA
- TGI2-R36A
- TGI2-T36A
Specifications
Manufacturer SawStop Part Number ICS31230-TGI236 Manufacturer's Part ICS31230-TGI236 Weight 772.000 lbs UPC/EAN Code 857555005062 Arbor Runout 0.001" Blade 40 Teeth Titanium, 5/8" Arbor Blade Kerf 0.118" Blade Plate Thickness 0.078" Blade Tilt Left Extension Wings 10" x 30" Main Bearing Size 62 mm OD x 30 mm ID Motor Configuration 1 ICS31230: 3 HP, 1 phase, 230v, 13 A, 60Hz, TEFC Overall Saw Dimensions 36 69 1/4" W x 36 1/2" D x 34" H Saw Blade Diameter 10" Saw Body Footprint 20" W x 25" D (Cabinet) Second Bearing Size 52 mm OD x 25 mm ID
