Product details
| Manufacturer: | Freud |
| Part Number: | 77-109-FRD |
| MPN: | 77-109 |
A combination of up and down shear flutes allow these bits to produce clean, chip-free top and bottom surfaces in double-sided veneers or laminates. The single-flute design is ideal for fast routing in almost any material, including hardwood, softwood, plywood or composites. Although these bits are most often used in CNC machines, they may also be used in router tables or in hand-held routing applications.
• Fast, chip-free routing in double-sided materials
• Use on CNC routers as well as hand-held and table-mounted portable routers
• Black I.C.E. coating for cool cutting edge and superior chip evacuation
• Freud Premier Solid Carbide
• Black I.C.E. + Freud TiCo™ Hi-Density Carbide = 2X increased life and performance vs. standard uncoated bits
Ideal For: hardwood, softwood, plywood or composites
• Fast, chip-free routing in double-sided materials
• Use on CNC routers as well as hand-held and table-mounted portable routers
• Black I.C.E. coating for cool cutting edge and superior chip evacuation
• Freud Premier Solid Carbide
• Black I.C.E. + Freud TiCo™ Hi-Density Carbide = 2X increased life and performance vs. standard uncoated bits
Ideal For: hardwood, softwood, plywood or composites
Used for Cutting:
Hardwoods
Softwoods
Veneered Plywood
Composites
Specifications
Manufacturer Freud Part Number 77-109-FRD Manufacturer's Part 77-109 Weight 0.360 lbs UPC/EAN Code 8925016922 Diameter 1/2" Shank Diameter 1/2" Overall Length 3-1/2" Type Compression Material Solid Carbide No. of Cutters 1 Max. RPM 24,000 RPM Carbide Height 1-1/2"
